Intro .
HICL panel PCs, including fanless panel PCs and other multifunctional panel PCs, combine a CPU board, LCD display, and user-friendly human machine interface touchscreen within a slick, compact chassis. Each fanless panel PC and other multifunctional panel PCs are compact, highly integrated, network-ready computer with the fullest I/O connectivity.
| Product ModelPanel PC |
| Product Size7" |
|
Product Description |
Features:
CPU Geode@LX800 CPU On Board
OnBoard 256M DDR
Nicely design with Rugged steel housing fully enclosed chassis and aluminum front bezel
Ultra-low power consumption
Supports DDC 1/2B for Plug & Play compatibility
Advanced OSD control for picture quality adjustment and sound
Specification
System |
CPU |
AMD Geode@LX800 on Board Processor, up to 500MHz |
Chipset |
AMD Geode@ LX800 |
Memory |
OnBoard 256M DDR |
CF card |
8GB |
Network(LAN) |
10/100 Mbps Ethernet |
Audio |
Mic-in, Line-out, Line-in |
SSD |
Optional |
I/O Ports |
1 x PS2 for KB/ Mouse |
1 x 10/100 LAN port |
1 x VGA |
1 x Lin-in / Lin-out / Mic-in |
4 x USB |
2 x COM 1 x LPT |
OS Support |
Microsoft |
Windows XP, CE |
Power Supply |
Input Voltage |
100~240VAC,50/60Hz |
LCD Display |
Display Type/Size |
7"TFT LCD |
Screen Resolution |
800 x 480 |
Brightness |
300cd/m2 |
Pixel Pitch |
0.0635 x 0.1905 |
Viewing Angle |
70/70/60/60 |
BackLight Lifetime |
30000hrs |
Touch Screen(optional) |
Type |
Analog Resistive 5 wires |
Resolution |
4096*4096 |
Light Transmission |
>90% |
Controller |
USB/RS232 interface |
Mechanical |
Construction |
IP65 / NEMA compliant |
Front Panel Protection |
Aluminum Front Bezel and Steel Enclosure |
Certification |
Compliance |
CE,FCC,RoHS |
Ordering Information |
ITD07PPCT1O1 |
7"Inudstrial panel PC with touch |
ITD07PPCN1O1 |
7"Industrial panel PC without touch |
|
|
